CCU20A231RNIUX - Indoor Cooling Unit 2000W 230V~1 RAL7035

Indoor Cooling Unit 2000W 230V~1 RAL7035

More information: "Indoor Cooling Unit 2000W 230V~1 RAL7035"

The CCU series roof-mounted cooling units represent an ideal solution for cooling battery electrical panels or when accessibility and lateral space are limited, ensuring high technical and safety standards. In all models, the polyurethane gasket is laid by machine, significantly reducing installation times.

Documentation available

Document list

Document type Format Size Action
General Safety Instructions .pdf 0.32 MB Download
Mounting cut-out mm (in) .pdf 0.01 MB Download
Mounting Instructions .pdf 0.66 MB Download
Wiring Diagram .pdf 0.06 MB Download
Declaration Of Conformity EU .pdf 0.14 MB Download
Declaration Of Conformity UKCA .pdf 0.13 MB Download

APPROVALS

Approvals CE; UKCA

ELECTRICAL DATA

Frequency 50/60 Hz
Fuse T 12 A
Max Current 26 A
Rated Current 6/6.6 A
Rated Power L35L35 925/1065 W
Rated Power L35L50 1075/1295 W
Rated Voltage 230 V a.c.

ENVIRONMENTAL AND THERMAL DATA

Operating Temperature 20÷50 °C
Protection Degree Internal Circuit IP54

GENERIC DATA

Cable Length 2000 mm
Casing Material Painted Steel
Electrical Connection Wires
Maximum Allowable Pressure HP 2.4/LP 0.6 MPa
RAL Number 7035
Refrigerant Charge 680 g
Refrigerant Number R134a

PERFORMANCE

Cooling Capacity L35L35 1955/2145 W
Cooling Capacity L35L50 1565/1635 W
